Description
Hydraulic Swing Arm Cutting Machine
Applications and features
1、Applies to cut one layer or several layers of leather, rubber sheet, nylon sheet, sponge etc.
2、Low power consumption, and high speed.
3、Using special hydraulic circuit system, convenient to adjust the swing arm height, and no need to make any adjustment if the height of die cutter is changed.
4、Solid body structure, low noise and few breakdown.
5、With different cutting force, materials can be cut into various of patterns.
6、attached special little cutting press.
The main parameters
|
Model |
DM-920 (1+3) |
DM-927 |
|
Dimensions |
90*75*130cm |
100*112*166 |
|
Cutting area |
90*43cm |
100*50cm |
|
M.C.F. |
20T |
27T |
|
Motor power |
2HP/1.5KW |
2HP/1.5KW |
|
10-100mm |
10-100mm |
|
|
N.W. |
600 kgs |
900 kgs |
